IP68 Hi-End Connectors for Lighting & Industrial
TEEPLUG-v2
Product name (Series)TH387 - mini-Plug&Socket connector IP66/IP68 Product configurationSocket connector (cable-to-cable) Number of poles2 Type of connectioninsulation piercing screw (M3 - max. 1.0 Nm) Cable diameter min. - max.7.0 mm - 13.5 mm Operating currentmax. 17.5A Operating voltagemax. 450V AC Wire cross-section min. - max. (Stranded cable)0.5 mm2 - 1.5 mm2
ขายแล้ว 0 ชิ้น
THP.387.A2A.L
Product name (Series)TH387 - mini-Plug&Socket connector IP66/IP68 Product configurationPlug connector (cable-to-cable) Number of poles2 Type of connectioninsulation piercing screw (M3 - max. 1.0 Nm) Cable diameter min. - max.7.0 mm - 13.5 mm Operating currentmax. 17.5A Operating voltagemax. 450V AC Wire cross-section min. - max. (Stranded cable)0.5 mm2 - 1.5 mm2
ขายแล้ว 0 ชิ้น
THB.387.A2A
Product name (Series)TH387 - mini-Plug&Socket connector IP66/IP68 Product configurationPlug connector (cable-to-cable) Number of poles2 Type of connectionscrew (M3 - max. 0.5 Nm) Cable diameter min. - max.7.0 mm - 12.0 mm Operating currentmax. 17.5A Operating voltagemax. 450V AC Wire cross-section min. - max. (Stranded cable)0.5 mm2 - 4.0 mm2
ขายแล้ว 0 ชิ้น
THB.387.B2A
Product name (Series)TH387 - mini-Plug&Socket connector IP66/IP68 Product configurationSocket connector (cable-to-cable) Number of poles2 Type of connectionscrew (M3 - max. 0.5 Nm) Cable diameter min. - max.7.0 mm - 12.0 mm Operating currentmax. 17.5A Operating voltagemax. 450V AC Wire cross-section min. - max. (Stranded cable)0.5 mm2 - 4.0 mm2
ขายแล้ว 0 ชิ้น
![THB.211.A3A TH211 - Junction box 3 ways type "T" IP65](https://image.makewebeasy.net/makeweb/r_409x409/r0KqYKwpJ/TECHNO/product_m_TH211_1.jpg?v=202405291424 "THB.211.A3A TH211 - Junction box 3 ways type "T" IP65")
THB.211.A3A
Product name (Series)TH211 - Junction box 3 vie tipo "T" IP65 Product configurationJunction box with terminal block Number of poles3 Type of connectionscrew (M3 - max. 0.5 Nm) Cable diameter min. - max.8.0 mm - 17.0 mm (main cable) / 8.0 mm - 17.0 mm (branch cable) Operating currentmax. 24A Operating voltagemax. 450V AC Wire cross-section min. - max. (Stranded cable)0.5 mm2 - 4.0 mm2
ขายแล้ว 0 ชิ้น
![THB.209.A3A TH209 - Junction box 4 ways type "H" IP68](https://image.makewebeasy.net/makeweb/r_409x409/r0KqYKwpJ/TECHNO/product_m_TH209_1.jpg?v=202405291424 "THB.209.A3A TH209 - Junction box 4 ways type "H" IP68")
THB.209.A3A
Product name (Series)TH209 - Junction box 4 vie tipo "H" IP68 Product configurationJunction box with terminal block Number of poles3 Type of connectionscrew (M3 - max. 0.5 Nm) Cable diameter min. - max.7.0 mm - 14.0 mm (main cable) / 7.0 mm - 14.0 mm (branch cable) Operating currentmax. 24A Operating voltagemax. 450V AC Wire cross-section min. - max. (Stranded cable)0.5 mm2 - 4.0 mm2
ขายแล้ว 0 ชิ้น
![THB.200.E3F TH200 - mini-Junction box 3 ways type "T" IP67](https://image.makewebeasy.net/makeweb/r_409x409/r0KqYKwpJ/TECHNO/product_03_1.jpg?v=202405291424 "THB.200.E3F TH200 - mini-Junction box 3 ways type "T" IP67")
THB.200.E3F
Product name (Series)TH200 - mini-Junction box 3 vie tipo "T" IP67 Product configurationJunction box with terminal block Number of poles3 Type of connectionscrew (M3 - max. 0.5 Nm) Cable diameter min. - max.7.5 mm - 9.5 mm (main cable) / 7.5 mm - 9.5 mm (branch cable) Operating currentmax. 16A Operating voltagemax. 250V AC Wire cross-section min. - max. (Stranded cable)0.5 mm2 - 1.5 mm2
ขายแล้ว 0 ชิ้น
![THB.392.A4A.L TH392 - Circular mini-junction connector 4 ways type "H" IP68](https://image.makewebeasy.net/makeweb/r_409x409/r0KqYKwpJ/TECHNO/product_TH392_A4_1.jpg?v=202405291424 "THB.392.A4A.L TH392 - Circular mini-junction connector 4 ways type "H" IP68")
THB.392.A4A.L
Product name (Series)TH392 - Circular mini-junction connector 4 vie tipo "H" IP68 Product configurationIn-line joint connector Number of poles4 Type of connectionscrew (M3 - max. 0.5 Nm) Cable diameter min. - max.7.0 mm - 13.5 mm (main cable) / 7.0 mm - 13.5 mm (branch cable) Operating currentmax. 17.5A Operating voltagemax. 450V AC Wire cross-section min. - max. (Stranded cable)0.5 mm2 - 4.0 mm2
ขายแล้ว 0 ชิ้น
![THB.392.A4A.R TH392 - Circular mini-junction connector 4 ways type "H" IP68](https://image.makewebeasy.net/makeweb/r_409x409/r0KqYKwpJ/TECHNO/product_TEETUBE_TH392_725_1.jpg?v=202405291424 "THB.392.A4A.R TH392 - Circular mini-junction connector 4 ways type "H" IP68")
THB.392.A4A.R
Product name (Series)TH392 - Circular mini-junction connector 4 vie tipo "H" IP68 Product configurationIn-line joint connector Number of poles4 Type of connectionscrew (M3 - max. 0.5 Nm) Cable diameter min. - max.5.0 mm - 12.0 mm (main cable) / 5.0 mm - 12.0 mm (branch cable) Operating currentmax. 17.5A Operating voltagemax. 450V AC Wire cross-section min. - max. (Stranded cable)0.5 mm2 - 4.0 mm2
ขายแล้ว 0 ชิ้น
![THB.399.F2A TH399 - Circular mini-junction connector 3 ways type "Y" IP68](https://image.makewebeasy.net/makeweb/r_409x409/r0KqYKwpJ/TECHNO/th399.jpg?v=202405291424 "THB.399.F2A TH399 - Circular mini-junction connector 3 ways type "Y" IP68")
THB.399.F2A
Product name (Series)TH399 - Circular mini-junction connector 3 vie tipo "Y" IP68 Product configurationIn-line joint connector Number of poles2 Type of connectionscrew (M3 - max. 0.5 Nm) Cable diameter min. - max.8.0 mm - 17.0 mm (main cable) / 8.0 mm - 17.0 mm (branch cable) Operating currentmax. 32A Operating voltagemax. 450V AC Wire cross-section min. - max. (Stranded cable)0.5 mm2 - 1.5 mm2
ขายแล้ว 0 ชิ้น
![THB.402.C2C TH402 - Circular junction connector 3 ways type "T" IP68](https://image.makewebeasy.net/makeweb/r_409x409/r0KqYKwpJ/TECHNO/product_TH399_E_1.jpg?v=202405291424 "THB.402.C2C TH402 - Circular junction connector 3 ways type "T" IP68")
THB.402.C2C
Product name (Series)TH402 - Giunto circolare di derivazione a 3 vie tipo "T" IP68 Product configurationIn-line joint connector Number of poles2 Type of connectionscrew (M3 - max. 0.5 Nm) Cable diameter min. - max.7.0 mm - 13.5 mm (main cable) / 7.0 mm - 13.5 mm (branch cable) Operating currentmax. 32A Operating voltagemax. 450V AC Wire cross-section min. - max. (Stranded cable)0.5 mm2 - 4.0 mm2
ขายแล้ว 0 ชิ้น
![THB.390.C3B TH390 - Circular mini-junction connector 3 ways type "T" IP68](https://image.makewebeasy.net/makeweb/r_409x409/r0KqYKwpJ/TECHNO/product_TH390_B_1.jpg?v=202405291424 "THB.390.C3B TH390 - Circular mini-junction connector 3 ways type "T" IP68")
THB.390.C3B
Product name (Series)TH390 - Circular mini-junction connector 3 vie tipo "T" IP68 Product configurationIn-line joint connector Number of poles2 Type of connectionscrew with push-wire clamp (M3 - max. 0.5 Nm) Cable diameter min. - max.7.0 mm - 13.5 mm (main cable) / 7.0 mm - 13.5 mm (branch cable) Operating currentmax. 24A Operating voltagemax. 450V AC Wire cross-section min. - max. (Stranded cable)0.25 mm2 - 1.5 mm2
ขายแล้ว 0 ชิ้น
![THP.401.A1C TH401 - In-line circular joint connector angled 90° type "L" IP68](https://image.makewebeasy.net/makeweb/r_409x409/r0KqYKwpJ/TECHNO/THP_401_A1C.jpg?v=202405291424 "THP.401.A1C TH401 - In-line circular joint connector angled 90° type "L" IP68")
THP.401.A1C
Product name (Series)TH401 - Giunto circolare di connessione angled 90° tipo "L" IP68 Product configurationIn-line joint connector Number of poles2 Type of connectioninsulation piercing screw (M3 - max. 1.0 Nm) Cable diameter min. - max.7.0 mm - 13.5 mm (input) / 7.0 mm - 13.5 mm (output) Operating currentmax. 17.5A Operating voltagemax. 450V AC Wire cross-section min. - max. (Stranded cable)0.5 mm2 - 1.5 mm2
ขายแล้ว 0 ชิ้น
![THB.400.D1M TH400 - In-line circular joint connector type "I" IP68](https://image.makewebeasy.net/makeweb/r_409x409/r0KqYKwpJ/TECHNO/THB_400_D3M.jpg?v=202405291424 "THB.400.D1M TH400 - In-line circular joint connector type "I" IP68")
THB.400.D1M
Product name (Series) TH400 - Giunto circolare di connessione lineare tipo "I" IP68 Product configuration In-line joint connector Number of poles 2 Type of connection screw (M3 - max. 0.5 Nm) Cable diameter min. - max. 8.0 mm - 17.0 mm Operating current max. 32A Operating voltage max. 450V AC Wire cross-section min. - max. (Stranded cable) 0.5 mm2 - 4.0 mm2
ขายแล้ว 0 ชิ้น
THB.400.D3M
Product name (Series) TH400 - Giunto circolare di connessione lineare tipo "I" IP68 Product configuration In-line joint connector Number of poles 2 Type of connection screw with push-wire clamp (M3 - max. 0.5 Nm) Cable diameter min. - max. 8.0 mm - 17.0 mm Operating current max. 24A Operating voltage max. 450V AC Wire cross-section min. - max. (Stranded cable) 0.25 mm2 - 2.5 mm2
ขายแล้ว 0 ชิ้น
![THP.390.A1B TH390 - In-line circular mini-joint connector type "I" IP68](https://image.makewebeasy.net/makeweb/r_409x409/r0KqYKwpJ/TECHNO/THB_390_A3B.jpg?v=202405291424 "THP.390.A1B TH390 - In-line circular mini-joint connector type "I" IP68")
THP.390.A1B
Product name (Series) TH390 - In-line circular mini-joint connector tipo "I" IP68 Product configuration In-line joint connector Number of poles 2 Type of connection insulation piercing screw (M3 - max. 1.0 Nm) Cable diameter min. - max. 7.0 mm - 13.5 mm Operating current max. 17.5A Operating voltage max. 450V AC Wire cross-section min. - max. (Stranded cable) 0.5 mm2 - 1.5 mm2
ขายแล้ว 0 ชิ้น
THB.390.A1B
Product name (Series) TH390 - In-line circular mini-joint connector tipo "I" IP68 Product configuration In-line joint connector Number of poles 2 Type of connection screw (M3 - max. 0.5 Nm) Cable diameter min. - max. 7.0 mm - 13.5 mm Operating current max. 32A Operating voltage max. 450V AC Wire cross-section min. - max. (Stranded cable) 0.5 mm2 - 4.0 mm2
ขายแล้ว 0 ชิ้น
THB.390.A3B
Product name (Series) TH390 - In-line circular mini-joint connector tipo "I" IP68 Product configuration In-line joint connector Number of poles 2 Type of connection screw with push-wire clamp (M3 - max. 0.5 Nm) Cable diameter min. - max. 7.0 mm - 13.5 mm Operating current max. 24A Operating voltage max. 450V AC Wire cross-section min. - max. (Stranded cable) 0.25 mm2 - 2.5 mm2
ขายแล้ว 0 ชิ้น
![THB.391.A3A.L TH391 - In-line circular mini-joint connector type "I" IP68/IP69K](https://image.makewebeasy.net/makeweb/r_409x409/r0KqYKwpJ/TECHNO/391.jpg?v=202405291424 "THB.391.A3A.L TH391 - In-line circular mini-joint connector type "I" IP68/IP69K")
THB.391.A3A.L
Product name (Series) TH391 - In-line circular mini-joint connector tipo "I" IP68/IP69K Product configuration In-line joint connector Number of poles 3 Type of connection screw (M3 - max. 0.5 Nm) Cable diameter min. - max. 7.0 mm - 13.5 mm Operating current max. 32A Operating voltage max. 450V AC Wire cross-section min. - max. (Stranded cable) 0.5 mm2 - 4.0 mm2
ขายแล้ว 0 ชิ้น
![THB.391.A3C.L TH391 - In-line circular mini-joint connector type "I" IP68/IP69K](https://image.makewebeasy.net/makeweb/r_409x409/r0KqYKwpJ/TECHNO/product_THB_391_1477924898_1.jpg?v=202405291424 "THB.391.A3C.L TH391 - In-line circular mini-joint connector type "I" IP68/IP69K")
THB.391.A3C.L
Product name (Series) TH391 - In-line circular mini-joint connector tipo "I" IP68/IP69K Product configuration In-line joint connector Number of poles 3 Type of connection screw with push-wire clamp (M3 - max. 0.5 Nm) Cable diameter min. - max. 7.0 mm - 13.5 mm Operating current max. 24A Operating voltage max. 450V AC Wire cross-section min. - max. (Stranded cable) 0.25 mm2 - 2.5 mm2
ขายแล้ว 0 ชิ้น
