Size(included cover) | Model | Mounting Plate | |||||
---|---|---|---|---|---|---|---|
W X L X H (mm) | W X L X H (inch) | ABS | PC | Steel 1.6mm | Plastic 3~4.5mm | ||
Grey cover | Transparent cover | Grey cover | Transparent cover | ||||
190x190x130 | 7.48x7.48x5.12 | BC-AGH-191913 | BC-ATH-191913 | BC-CGH-191913 | BC-CTH-191913 | 1919 S | 1919 P |
190x280x100 | 7.48x11.02x3.94 | BC-AGH-192810 | BC-ATH-192810 | BC-CGH-192810 | BC-CTH-192810 | 1928 S | 1928 P |
280x190x100 | 11.02x7.48x3.94 | BC-AGH-281910 | BC-ATH-281910 | BC-CGH-281910 | BC-CTH-281910 | 1928 S | 1928 P |
190x280x130 | 7.48x11.02x5.12 | BC-AGH-192813 | BC-ATH-192813 | BC-CGH-192813 | BC-CTH-192813 | 1928 S | 1928 P |
280x190x130 | 11.02x7.48x5.12 | BC-AGH-281913 | BC-ATH-281913 | BC-CGH-281913 | BC-CTH-281913 | 1928 S | 1928 P |
190x280x180 | 7.48x11.02x7.09 | BC-AGH-192818 | BC-ATH-192818 | BC-CGH-192818 | BC-CTH-192818 | 1928 S | 1928 P |
280x190x180 | 11.02x7.48x7.09 | BC-AGH-281918 | BC-ATH-281918 | BC-CGH-281918 | BC-CTH-281918 | 1928 S | 1928 P |
190x380x130 | 7.48x14.96x5.12 | BC-AGH-193813 | BC-ATH-193813 | BC-CGH-193813 | BC-CTH-193813 | 1938 S | 1938 P |
380x190x130 | 14.96x7.48x5.12 | BC-AGH-082508 | BC-ATH-381913 | BC-CGH-082508 | BC-CTH-082508 | 1938 S | 1938 P |
190x380x180 | 7.48x14.96x7.09 | BC-AGH-193818 | BC-ATH-193818 | BC-CGH-193818 | BC-CTH-193818 | 1938 S | 1938 P |
380x190x180 | 14.96x7.48x7.09 | BC-AGH-381918 | BC-ATH-381918 | BC-CGH-381918 | BC-CTH-381918 | 2828 S | 2828P |
280x280x130 | 11.02x11.02x5.12 | BC-AGH-282813 | BC-ATH-282813 | BC-CGH-282813 | BC-CTH-282813 | 2834 S | 2834P |
280x340x130 | 11.02x13.39x5.12 | BC-AGH-283413 | BC-ATH-283413 | BC-CGH-283413 | BC-CTH-283413 | 2834 S | 2834 P |
340x280x130 | 13.39x11.02x5.12 | BC-AGH-342813 | BC-ATH-342813 | BC-CGH-342813 | BC-CTH-342813 | 2838 S | 2838 P |
280x380x130 | 11.02x14.96x5.12 | BC-AGH-283813 | BC-ATH-283813 | BC-CGH-283813 | BC-CTH-283813 | 2838 S | 2838 P |
380x280x130 | 14.96x11.02x5.12 | BC-AGH-382813 | BC-ATH-382813 | BC-CGH-382813 | BC-CTH-382813 | 2838 S | 2838 P |
280x380x180 | 11.02x14.96x7.09 | BC-AGH-283818 | BC-ATH-283818 | BC-CGH-283818 | BC-CTH-283818 | 2838 S | 2838 P |
380x280x180 | 14.96x11.02x7.00 | BC-AGH-382818 | BC-ATH-382818 | BC-CGH-382818 | BC-CTH-382818 | 1217 S | 1217 P |
280x560x130 | 11.02x22.05x5.12 | BC-AGH-285613 | BC-ATH-285613 | BC-CGH-285613 | BC-CTH-285613 | 2856 S | - |
560x280x130 | 22.05x11.02x5.12 | BC-AGH-562813 | BC-ATH-562813 | BC-CGH-562813 | BC-CTH-562813 | 2856 S | - |
330x430x180 | 12.99x16.93x7.09 | BC-AGH-334318 | BC-ATH-334318 | BC-CGH-334318 | BC-CTH-334318 | 3343 S | 3343P |
430x330x180 | 16.93x12.99x7.09 | BC-AGH-433318 | BC-ATH-433318 | BC-CGH-433318 | BC-CTH-433318 | 3343 S | 3343 P |
380x560x180 | 14.96x22.05x7.09 | BC-AGH-385618 | BC-ATH-385618 | BC-CGH-385618 | BC-CTH-385618 | 3856 S | - |
560x380x180 | 22.05x14.96x7.09 | BC-AGH-563818 | BC-ATH-563818 | BC-CGH-563818 | BC-CTH-563818 | 3856 S | - |
