RNVT Series Plastic Breathable Valve
RNVT SERIES PLASTIC BREATHABLE VALVE
SPECIFICATION
Material : UL Approved Nylon PA66, UL94-V2
O - Ring : NBR
Protection degree : IP67
Color : Black, Light Grey
Hermetic seal : NBR
Temperature : Static state:-40 to 100, short time to 120;
Dynamic state : -20 to 80,short time to 100
Certification : TUV, CE, UL94-V2,RoHs
| (M) Code | Thread Size | Thread O. D. G | Thread Length L | Cover Dimensions D (mm) | Air permeabilty |
| RNVT-M12 | M12x1.5 | 12 | 9 | 16 | 180 |
| RNVT-M16 | M16x1.5 | 16 | 9 | 19 | 180 |
| RNVT-M18 | M18x1.5 | 18 | 9 | 22 | 180 |
| RNVT-M20 | M20x1.5 | 20 | 11 | 25 | 340 |
| RNVT-M22 | M22x1.5 | 22 | 11 | 27 | 340 |
| RNVT-M25 | M25x1.5 | 25 | 11 | 30 | 470 |
