The polyester weaving added in the middle for platinum vulcanization silicone hose, which can be used to delivery the low pressure liquid.
หมวดหมู่ : FLEXIBLE DUCT & HOSES ,  Foods & Chemical Hose ,
Share
P-1162 SILIFLEX HOSES
Application: For delivering liquid in the pharmaceutical and beauty cosmetics industry, edible oil and vinegar, wine and liquor lower 50% alcohol degree. The transparent stainless steel wire silicone hoses have the smooth inner and cover which can make the material flow smoothly.
Technical Description :
The structure has a good bending radius and suitable for high temperature and high pressure SIP and high temperature CIP. Odorless, tasteless, non-toxic, does not contain any additives and plsticizer. These tubes are usually translucent and the movement of fluid inside can be observed. The hose color cand be customized according to customer's need.
Temperature range : From -60 to +200° C
Standard/Approval : US Pharmacopeia Class VI-test Report; Compliance: FDA 21 CFR 177.2600 GTB-4806.11-2016 GB-31604.30.
No. | Size(inc.) | Internal diameter. (mm.) | External diameter. (mm.) | Working Pressure (bar) | Burst Pressure (bar) |
1 | 1/4" | 6.35 | 13.2 | 17 | 56 |
2 | 5/16" | 7.93 | 15.0 | 15 | 46 |
3 | 3/8" | 9.52 | 16.6 | 14 | 42 |
4 | 1/2" | 12.70 | 22.2 | 11 | 34 |
5 | 5/8" | 15.84 | 25.0 | 10 | 30 |
6 | 3/4" | 19.05 | 31.8 | 7 | 22 |
7 | 1" | 25.40 | 37.5 | 6 | 18 |
8 | 1-1/4" | 31.75 | 44.0 | 5 | 15 |
