CHI-16 C-Type Bulkhead Mount Housing | Connector 16 pin,Connector 16 pole
คุณสมบัติสินค้า:
The ILME CHI-16 C-Type bulkhead mount standard housing is size 77.27 and features two levers. The body is epoxy coated die cast aluminum with polyamide handles and stainless steel levers. Insert center distance: 77.5 x 27 mm. Rated IP 66 when attached and locked down. The clamping force supplied by the CHI-16 is constant with a life expectancy of at least 500 cycles.
หมวดหมู่ : CONNECTORS , ILME Multipole Connectors ,
แบรนด์ : ILME
Share
The ILME CHI-16 C-Type bulkhead mount standard housing is size 77.27 and features two levers. The body is epoxy coated die cast aluminum with polyamide handles and stainless steel levers. Insert center distance: 77.5 x 27 mm. Rated IP 66 when attached and locked down. The clamping force supplied by the CHI-16 is constant with a life expectancy of at least 500 cycles.
| Specifications | |
| Brand | ILME |
| Body | Epoxy Coated Die Cast Aluminum |
| Gasket | Thermoplastic Elastomer |
| Handle | Polyamide |
| Lever | Stainless Steel |
| ILME Series | CH |
| Insert Dimension | 77.27 |
| Enclosure Dimension | 77.27 |
| Housing Type | Standard |
| Enclosure Type | 2 Levers |
| Mounting Style | Bulkhead Mount |
| Temperature Range | 40 C to 125 C (-40 F to 257 F) |
| Gasket | Yes |
| Ingress Protection | IP66 (and IP69 DIN 40050 - 9) |
| Insert Center Distance | 77.5 x 27 mm. |
| Approvals | C UR US, CCC, GL |
